A Filament select component that lets you search and pick unDraw illustrations with image thumbnails in the dropdown and in the selected value.

PHP 8.2+, Filament Forms 5.x.

#Install

composer require zpmlabs/filament-undraw

#Filament theme setup

If your Filament panel uses a custom Tailwind theme, add both package paths to your theme file so Tailwind can see the classes used by the package:

@source '../../../../vendor/zpmlabs/filament-undraw/src/**/*';
@source '../../../../vendor/zpmlabs/filament-undraw/resources/views/**/*';

Both are needed for different reasons:

• src/**/* is required because the field component stores configurable utility classes like w-24 h-24 and w-40 h-40 inside PHP strings.
• resources/views/**/* is required because the packaged demo page view uses Tailwind classes directly in Blade.

After adding the sources, rebuild your assets:

npm run build

#Version support

• main / v5.x tags: Filament 5
• v4 branch / v4.x tags: Filament 4

#If you want to customize the view:

php artisan vendor:publish --tag=filament-undraw-views

• This will copy the blade file to resources/views/vendor/filament-undraw/undraw-select.blade.php.

#Usage

use ZPMLabs\FilamentUndraw\Forms\Components\UndrawSelect;

UndrawSelect::make('svg_url'),

Since this extends Filament's Select, you can keep using the usual fluent methods alongside the custom thumbnail layout.

#Ready-to-use demo page

The package ships with an example Filament page you can mount directly in your panel:

use CommunitySdks\UnlayerFilament\Examples\Pages\UnlayerFilamentDemoPage;
use Filament\Pages\Dashboard;
use ZPMLabs\FilamentUndraw\Examples\Pages\UndrawDemoPage;

$panel->pages([
	Dashboard::class,
	UnlayerFilamentDemoPage::class,
	UndrawDemoPage::class,
]);

Example field presets used on the page:

use ZPMLabs\FilamentUndraw\Forms\Components\UndrawSelect;

UndrawSelect::make('hero_illustration')
	->label('Hero illustration')
	->live();

UndrawSelect::make('compact_illustration')
	->label('Compact illustration')
	->searchResultSize('w-24 h-24')
	->selectedOptionSize('w-24 h-24')
	->limit(12);

#Expanding Undraw Usage

In case you want to expand this in some other field or custom component you can check the base php package for undraw.
