A generic Laravel workflow orchestration package with pluggable step executors and an optional Filament admin UI.

#Features

• Interval and fixed-time daily workflow scheduling.
• Queue-driven workflow execution with pluggable step executors.
• Stale run protection and overlap control.
• Filament integration with a single Workflows navigation entry:
  • Steps relation manager for workflow step configuration.
  • Runs relation manager for history.
  • Run steps visible in a modal from each run row.

#Compatibility Matrix

#Release Lines

• ^1.x (Filament v5) is the default and latest release line.
• ^0.4.x is the Filament v4 maintenance line.
• ^0.3.x is the Filament v3 maintenance line.

#Latest Tags

• 1.0.3 for Filament v5 projects.
• 0.4.1 for Filament v4 projects.
• 0.3.1 for Filament v3 projects.

#Installation

1. Require the package for your Filament major.

composer require briefley/filament-workflow-builder:^1.0 # Filament v5
composer require briefley/filament-workflow-builder:^0.4 # Filament v4
composer require briefley/filament-workflow-builder:^0.3 # Filament v3

2. Publish config and migrations.

php artisan vendor:publish --tag=workflow-builder-config
php artisan vendor:publish --tag=workflow-builder-migrations
php artisan migrate

#Maintenance Policy

• ^1.x (Filament v5) is the primary feature line.
• ^0.4.x (Filament v4) and ^0.3.x (Filament v3) are compatibility maintenance lines.
• New features are developed on ^1.x first, then selectively backported when safe.

#Configuration

Define available step types and executors in config/workflow-builder.php:

return [
    'workflow_jobs' => [
        'hello_world_job' => [
            'label' => 'Hello World Job',
        ],
    ],

    'step_executors' => [
        'hello_world_job' => App\Workflow\Executors\HelloWorldStepExecutor::class,
    ],
];

#Build Your Own Workflow Jobs

#1. Create a step executor

Each workflow "job" is a step type mapped to an executor class.

<?php

namespace App\Workflow\Executors;

use Briefley\WorkflowBuilder\Contracts\WorkflowStepExecutor;
use Briefley\WorkflowBuilder\DTO\StepExecutionResult;
use Briefley\WorkflowBuilder\Models\WorkflowRunStep;
use Illuminate\Support\Facades\Log;

class SendReportStepExecutor implements WorkflowStepExecutor
{
    public function execute(WorkflowRunStep $runStep): StepExecutionResult
    {
        // Run your business logic here (API call, file export, DB work, etc).
        Log::info('Report step executed', [
            'workflow_run_id' => $runStep->workflow_run_id,
            'workflow_run_step_id' => $runStep->id,
        ]);

        return StepExecutionResult::succeeded(meta: [
            'report_id' => 123,
        ]);
    }
}

#1.1 Pass data from previous steps (optional)

If your job needs outputs from earlier jobs in the same workflow run, implement:

• Briefley\WorkflowBuilder\Contracts\ContextAwareWorkflowStepExecutor

You will receive WorkflowStepExecutionContext containing succeeded previous step outputs (meta).

<?php

use Briefley\WorkflowBuilder\Contracts\ContextAwareWorkflowStepExecutor;
use Briefley\WorkflowBuilder\DTO\StepExecutionResult;
use Briefley\WorkflowBuilder\DTO\WorkflowStepExecutionContext;
use Briefley\WorkflowBuilder\Models\WorkflowRunStep;

class SendEmailsFromCsvStepExecutor implements ContextAwareWorkflowStepExecutor
{
    public function execute(WorkflowRunStep $runStep): StepExecutionResult
    {
        // Backward-compatible fallback when context is not available.
        return StepExecutionResult::failed('Missing context.');
    }

    public function executeWithContext(
        WorkflowRunStep $runStep,
        WorkflowStepExecutionContext $context,
    ): StepExecutionResult {
        $csvPath = $context->latestValueForStepType('generate_fake_users_csv_job', 'csv_path');

        if (! is_string($csvPath) || $csvPath === '') {
            return StepExecutionResult::failed('CSV path not found.');
        }

        // Continue with your step logic...
        return StepExecutionResult::succeeded();
    }
}

Helpful context methods:

• latestMetaForStepType(string $stepType): ?array
• latestValueForStepType(string $stepType, string $key, mixed $default = null): mixed
• metaForSequence(int $sequence): ?array
• valueForSequence(int $sequence, string $key, mixed $default = null): mixed

#2. Return one of the supported step results

Each step executor must implement:

• Briefley\WorkflowBuilder\Contracts\WorkflowStepExecutor

and return Briefley\WorkflowBuilder\DTO\StepExecutionResult from execute():

• StepExecutionResult::succeeded(...) for completed steps.
• StepExecutionResult::failed('reason') to fail the run.
• StepExecutionResult::waiting(...) for async polling-style steps.

#2.1 Production reliability tips

When implementing real jobs, these two patterns help avoid common production failures:

• Make retryable steps idempotent. Persist processed item identifiers (for example email addresses, external IDs, or row hashes) in step meta, and skip already-processed items on retry.
• Avoid dev-only runtime dependencies in executors. If your executor uses optional helpers/libraries (for example Faker), provide a fallback path so production installs with --no-dev do not crash.

#3. Register your step type in config

Add your label and executor to config/workflow-builder.php:

return [
    'workflow_jobs' => [
        'send_report_job' => [
            'label' => 'Send Report Job',
        ],
    ],

    'step_executors' => [
        'send_report_job' => App\Workflow\Executors\SendReportStepExecutor::class,
    ],
];

The step_executors key is the runtime source of truth.
The workflow_jobs key is used for friendly labels in UI selectors.

#4. Add the step in Filament

1. Open Workflows.
2. Create or edit a workflow.
3. In the Steps relation manager, add a row with your step type.
4. Order steps by sequence.

#5. Run scheduler + queue worker

The package dispatches due workflows from the scheduler, and steps execute in queue jobs.

php artisan schedule:work
php artisan queue:work

If you use Horizon, run Horizon instead of queue:work.

#Scheduler

Dispatch due workflows every minute from your scheduler:

Schedule::command('workflow-builder:dispatch-due')->everyMinute();

#Filament Plugin

Register the plugin in your panel provider:

->plugin(\Briefley\WorkflowBuilder\WorkflowBuilderPlugin::make())

The plugin registers only the WorkflowResource and manages steps/runs via relation managers.

#Testing

Run the package test suite:

composer test
