This package provides the Flexbox layout for the forms & infolists components in your Filament admin panel.

#Documentation

The Split layout Component in the Forms and Infolists of the Filament panel has been implemented using the CSS Flexbox, But unfortunatley it doesn't support important properties such as justify-content to manage the arrangement of its children.

The Flex layout Component solves this problem. The Flex is a sub-class of the Split component and provides additional APIs to align the Horizontal Arrangement (justify-content) and Flex Gap (gap).

[!IMPORTANT] The Children of the Flex component must be chained with ->grow(false) method for this to work.

#Horizontal Arrangement

The Horizontal placement can be managed using ->horizontalArrangement() method.

• HorizontalArrangement::Start - Justify content to the start of the container.
• HorizontalArrangement::Center - Justify content to the center of the container.
• HorizontalArrangement::End - Justify content to the end of the container.
• HorizontalArrangement::Evenly - Justify content with even spacing between them.
• HorizontalArrangement::Between - Justify content with space between them.
• HorizontalArrangement::Around - Justify content with space around them.

#Flex Gap

The Gap between the children can be controlled using the ->gap() method. The gap can be set to a specific value or a Tailwind CSS spacing utility class.

Flex::make([])
    ->gap(4) // will be translated to `gap-4` tailwind class

#Requirements

This package expects filament/filament package to be over v3.3.

#Installation

The package can be installed via Composer.

composer require kingmaker/filament-flex-layout

#Theming

[!NOTE] You need to use custom theme for the Flex component to work properly.

Add the plugin's views to your tailwind.config.js file.

export default{
  content: [
    '<path-to-vendor>/kingmaker/filament-flex-layout/resources/views/**/*.blade.php'
  ]
}

Then, add few classes (gap-*) to your tailwind config file's safelist.

export default{
  content: [
    '<path-to-vendor>/kingmaker/filament-flex-layout/resources/views/**/*.blade.php'
  ],
  safelist: [
    { pattern: /gap-/ },
  ]
}

#Usage

Within your Forms and Infolists schema definition, You can use the Flex layout Component provided by this package.

use Kingmaker\FilamentFlexLayout\Enums\HorizontalArrangement;
use Kingmaker\FilamentFlexLayout\Forms\Flex;

Flex::make([
    Forms\Components\Toggle::make('user_like')
        ->grow(false) // <<-- Important
        ->onIcon('heroicon-s-heart')
        ->offIcon('heroicon-o-heart')
        ->onColor('danger')
        ->offColor('gray'),
    Forms\Components\Toggle::make('user_read')
        ->grow(false) // <<-- Important
        ->onIcon('heroicon-s-book-open')
        ->offIcon('heroicon-s-book-open')
        ->onColor('success')
        ->offColor('gray'),
])
    ->horizontalArrangement(HorizontalArrangement::Evenly)

use Kingmaker\FilamentFlexLayout\Enums\HorizontalArrangement;
use Kingmaker\FilamentFlexLayout\Infolists\Flex;

Flex::make([])
    ->horizontalArrangement(HorizontalArrangement::Evenly)
    ->gap(12)

#API Reference

The Flex component is available for the forms and infolists

• Kingmaker\FilamentFlexLayout\Forms\Flex for forms layout.
• Kingmaker\FilamentFlexLayout\Infolists\Flex for infolists layout.

The Flex component extends the Split component and provides the following additional methods:

1. gap(int|string|Closure $value) - Set the gap between the children. The value can be a number or a Tailwind CSS spacing utility class.
2. horizontalArrangement(HorizontalArrangement|string|Closure $value) - Set the horizontal arrangement of the children.
   • The value can be one of the HorizontalArrangement enum values.
   • The value can be one of strings: start, center, end, evenly, between, around, stretch.
   • The value can be a closure that returns one of the above values.

#Utility Methods

1. horizontallyArrangeStart(Closure|bool $condition = true) - Set the horizontal arrangement to start if the condition is true.
2. horizontallyArrangeCenter(Closure|bool $condition = true) - Set the horizontal arrangement to center if the condition is true.
3. horizontallyArrangeEnd(Closure|bool $condition = true) - Set the horizontal arrangement to end if the condition is true.
4. horizontallyArrangeSpaceEvenly(Closure|bool $condition = true) - Set the horizontal arrangement to evenly if the condition is true.
5. horizontallyArrangeSpaceBetween(Closure|bool $condition = true) - Set the horizontal arrangement to between if the condition is true.
6. horizontallyArrangeSpaceAround(Closure|bool $condition = true) - Set the horizontal arrangement to around if the condition is true.
7. horizontallyArrangeStretch(Closure|bool $condition = true) - Set the horizontal arrangement to stretch if the condition is true.
8. horizontallyArrangeBaseline(Closure|bool $condition = true) - Set the horizontal arrangement to baseline if the condition is true.

#Contributing

Contributions are always welcome!

#License

This Package was being published under MIT License.
